µ-Slide 18 Well

可平行測試 18 種實驗條件，並呈現高品質的細胞顯微影像。
每個 well 僅需 0.5–1.1 x 10⁴ 細胞與 100 µl 的試劑用量。
ibiTreat 底部經特殊處理，適合各類細胞貼附生長，免去 coating 麻煩。
適合活細胞影像觀察攝影 (live cell imaging)、免疫螢光染色 (immunofluorescence)、細胞轉染 (transfection) …等實驗使用。

歡迎與我們聯繫索取更多 µ-Slide 18 Well 產品資訊與文獻。

產品特點

從細胞培養、染色到顯微鏡觀察“All-in-one”完成，一氣呵成高效便利

The ibidi Chambered Coverslips (e.g., µ-Slide 1 Well | 2 Well | 4 Well | 8 Well | 18 Well) allows for standard immunofluorescence protocols to be employed without the use of coverslips in an all-in-one chamber. All steps (e.g., cell cultivation, fixation, staining, and imaging) are carried out in the open well geometry. After staining, the sample can be observed through the coverslip bottom using high-resolution microscopy.

底部厚度符合 #1.5 蓋玻片，影像清晰易觀測

Fluorescence microscopy of human endothelial cells (HUVEC) in a µ-Slide 18 Well ibiTreat. Red: alpha-tubulin, green: F-actin, stained with LifeAct-TagGFP2 Protein; blue: nuclei (ibidi Mounting Medium with DAPI). 60x objective lens, oil immersion.

Fluorescence microscopy of rat fibroblasts (Rat1) in a µ-Slide 18 Well Glass Bottom. Red: alpha-tubulin, green: F-actin, stained with LifeAct-TagGFP2 Protein; blue: nuclei (ibidi Mounting Medium with DAPI). 60x objective lens, oil immersion.

產品規格

µ-Slide 18 Well 產品規格

Outer dimensions	W25.5 x L75.5 mm
Number of wells	18
Dimensions of wells	W5.7 x L6.1 x H6.8 mm
Total height with lid	8.2 mm
Volume per well	100 µl
Growth area per well	0.34 cm²
Coating area per well	1.15 cm²
Bottom	ibidi Polymer Coverslip or Glass coverslip No. 1.5H

ibidi Chambered Coverslips 產品規格比較

	µ-Slide 1 Well	µ-Slide 2 Well	µ-Slide 4 Well	µ-Slide 8 Well	µ-Slide 18 Well
Number of wells	1	2	4	8	18
Volume per well	3 ml	1500 µl	700 µl	300 µl	100 µl
Growth area per well	10.6 cm²	5.1 cm²	2.5 cm²	1.0 cm²	0.34 cm²
Outer dimensions	W25.5 x L75.5 mm
Bottom	ibidi Polymer Coverslip or Glass coverslip No. 1.5H

底部材質規格比較

	#1.5 ibidi Polymer Coverslip (ibidi 特殊塑料)	#1.5H ibidi Glass Coverslip (#1.5H 高精度玻璃)
Bottom thickness	180 µm (+10/-5 µm)	170 µm (+/-5 µm)
Bottom material	Polymer	D 263 M Schott high precision glass
Gas permeability	Yes	No
Compatibility with protein coatings	Yes	Yes
Immersion oil compatibility	Yes	Yes
Autofluorescence	Low	Low
Transmission	Very high (even ultraviolet)	High (ultraviolet restrictions)
Refractive index (nD 589 nm)	1.52	1.52
Brightfield Microscopy	++	++
Phase Contrast	++	++
Differential Interference Contrast (DIC)	++	++
Widefield Fluorescence	++	++
Confocal Fluorescence	++	++
Total Internal Reflection Fluorescence (TIRF)	+	++
Super-Resolution Microscopy	+	++

※更多材質特性比較資訊請見這裡。

訂購資訊

Product Name	Surface	Pack Size	Cat. No.
µ-Slide 18 Well	ibiTreat: #1.5 polymer coverslip, tissue culture treated, sterilized	15	IB-81816
µ-Slide 18 Well	Uncoated: #1.5 polymer coverslip, hydrophobic, sterilized	15	IB-81811
µ-Slide 18 Well Glass Bottom	Glass Bottom: #1.5H (170 µm +/- 5 µm) D 263 M Schott glass, sterilized	15	IB-81817
